Insert Boxes with Plastic Dividers

IBM


Carbide Insert Compartment Packaging
Insert Boxes with Plastic Dividers

IBM–Media

Ceramic Inserts Compartment Packaging Plastic Tackle box storage Sliding Lid Compartment Boxes Compartment Box Packaging Plastic Boxes with Molded Dividers Carbide Insert Compartment Packaging Carbide Insert Compartment Boxes Insert Boxes with Moulded Plastic Partitions
  • Material: PP (Polypropylene)
  • Features Individual Compartments
  • Simple Sliding Lid Opens in Either Direction
  • Locks Together When Stacking
  • Suitable for packaging items for vending machine sales
  • Available in a Wide Variety of Sizes, Styles and Cell Counts

Available in the following varieties:

IBM - Insert Boxes (Molded Partitions) Insert Boxes with Plastic Dividers
IBF - Insert Boxes (Foam Partitions) Insert Boxes with Foam Dividers

Size Chart Sliding Lid Compartment Boxes

IBM Size Chart

Table View
List View
Reference # Description Image Cell Count Inside Length
in
mm
 Inside Width
in
mm
 Inside Height
in
mm
 Outside Length
in
mm
 Outside Width
in
mm
 Outside Height
in
mm
 Box/Mini/Micro
QTY		 Buy Online
IB10/M1 Insert Boxes with Plastic Dividers - 31/64X31/64X1/4 (12.0 X12.0X6.6 MM) 10 CELL INSERT BOX IB10/M1 10
0.472
12.0
0.472
12.0
0.260
6.6
2.638
67.0
1.083
27.5
0.488
12.4
 500 100 10
IB02/M1 Insert Boxes with Plastic Dividers - 1.24X.98X.60 (31.40 x 24.9 x 15.2 MM) 2 CELL INSERT BOX IB02/M1 2
1.236
31.4
0.980
24.9
0.598
15.2
2.638
67.0
1.083
27.5
0.827
21.0
 500 100 10
IB01/M1 Insert Boxes with Moulded Plastic Partitions - 2.51X.98X.39 (63.8 x 24.9 x 10.0 MM) 1 CELL INSERT BOX IB01/M1 1
2.512
63.8
0.980
24.9
0.394
10.0
2.638
67.0
1.083
27.5
0.622
15.8
 500 100 10
IB02/M2 Carbide Insert Compartment Boxes - 2.51X.47X.60 (63.8 x 11.9 x 15.2 MM) 2 CELL INSERT BOX IB02/M2 2
2.512
63.8
0.469
11.9
0.598
15.2
2.638
67.0
1.083
27.5
0.827
21.0
 500 100 10
IB05/A1 Carbide Insert Compartment Packaging - .72X.72X.26 (18.3 x 18.3 x 6.6 MM) 5 CELL INSERT BOX IB05/A1 5
0.720
18.3
0.720
18.3
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB10/A1 Plastic Boxes with Molded Dividers - 23/32X23/32X1/4 (18.3X18.3X6.6 MM) 10 CELL INSERT BOX IB10/A1 10
0.720
18.3
0.720
18.3
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB02/A1 Compartment Box Packaging - 1.86X1.48X.26 (47.15 x 37.5 x 6.6 MM) 2 CELL INSERT BOX IB02/A1 2
1.856
47.2
1.476
37.5
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/A1 Sliding Lid Compartment Boxes - 3-3/4X1-15/32X1/4 (95.3X37.5X6.6 MM) 1 CELL INSERT BOX IB01/A1 1
3.752
95.3
1.476
37.5
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB10/A2 Plastic Tackle box storage - .47X.47X.26 (12.0 x 12.0 x 6.6 MM) 10 CELL INSERT BOX IB10/A2 10
0.472
12.0
0.472
12.0
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB05/A2 Insert Boxes with Plastic Dividers - 1-13/64X61/64X1/4 (30.5X24.4X6.6 MM) 5 CELL INSERT BOX IB05/A2 5
1.224
31.1
0.961
24.4
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB02/A2 Insert Boxes with Plastic Dividers - 1.86X1.48X.39 (47.15 x 37.5 x 10.0 MM) 2 CELL INSERT BOX IB02/A2 2
1.856
47.2
1.476
37.5
0.394
10.0
3.846
97.7
1.591
40.4
0.622
15.8
 500 100 10
IB10/A3 Insert Boxes with Moulded Plastic Partitions - .35X1.48X.32 (8.8 x 37.5 x 8.2 MM) 10 CELL INSERT BOX IB10/A3 10
0.346
8.8
1.476
37.5
0.323
8.2
3.846
97.7
1.591
40.4
0.551
14.0
 500 100 10
IB10/A4 Carbide Insert Compartment Boxes - 23/32X45/64X25/64 (18.4X18.4X10.0 MM) 10 CELL INSERT BOX IB10/A4 10
0.720
18.3
0.720
18.3
0.394
10.0
3.846
97.7
1.591
40.4
0.622
15.8
 500 100 10
IB10/A5 Carbide Insert Compartment Packaging - .57X1.02X.26 (14.4 x 25.8 x 6.6 MM) 10 CELL INSERT BOX IB10/A5 10
0.567
14.4
1.016
25.8
0.260
6.6
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB08/B1 Plastic Boxes with Molded Dividers - .63X2.09X.75 (15.9 x 53.0 x 19.0 MM) 8 CELL INSERT BOX IB08/B1 8
0.626
15.9
2.087
53.0
0.748
19.0
5.429
137.9
2.220
56.4
1.000
25.4
 250 50 5
IB05/B1 Compartment Box Packaging - 1-1/64X1-1/64X21/64 (26.0X26.0X8.2 MM) 5 CELL INSERT BOX IB05/B1 5
1.024
26.0
1.024
26.0
0.323
8.2
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB10/B1 Sliding Lid Compartment Boxes - 1-1/64X1-1/64X21/64 (26.0X26.0X8.2 MM) 10 CELL INSERT BOX IB10/B1 10
1.024
26.0
1.024
26.0
0.323
8.2
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB02/B1 Plastic Tackle box storage - 2.62X2.09X.50 (66.5 x 53.0 x 12.8 MM) 2 CELL INSERT BOX IB02/B1 2
2.618
66.5
2.087
53.0
0.504
12.8
5.429
137.9
2.220
56.4
0.756
19.2
 500 100 10
IB01/B1 Insert Boxes with Plastic Dividers - 5-9/32X2-5/64X35/64 (134.0X53.0X8.2 MM) 1 CELL INSERT BOX IB01/B1 1
5.276
134.0
2.087
53.0
0.323
8.2
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB05/B2 Insert Boxes with Plastic Dividers - 1.02X1.02X.50 (26.0 x 26.0 x 12.8 MM) 5 CELL INSERT BOX IB05/B2 5
1.024
26.0
1.024
26.0
0.504
12.8
5.429
137.9
2.220
56.4
0.756
19.2
 500 100 10
IB10/B2 Insert Boxes with Moulded Plastic Partitions - 1.02X1.02X.75 (26.0 x 26.0 x 19.0 MM) 10 CELL INSERT BOX IB10/B2 10
1.024
26.0
1.024
26.0
0.748
19.0
5.429
137.9
2.220
56.4
1.000
25.4
 250 50 5
IB02/B2 Carbide Insert Compartment Boxes - 2.62X2.09X.50 (66.5x53.0x12.8 MM) 2 CELL INSERT BOX W/POST IB02/B2 2
2.618
66.5
2.087
53.0
0.504
12.8
5.429
137.9
2.220
56.4
0.756
19.2
 500 100 10
IB05/B3 Carbide Insert Compartment Packaging - 1.02X2.09X.32 (26.0 x 53.0 x 8.2 MM) 5 CELL INSERT BOX IB05/B3 5
1.024
26.0
2.087
53.0
0.323
8.2
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB10/B3 Plastic Boxes with Molded Dividers - 1-1/32X1-1/32X35/64 (26.2X26.2X14. MM) 10 CELL INSERT BOX IB10/B3 10
1.032
26.2
1.032
26.2
0.551
14.0
5.429
137.9
2.220
56.4
0.803
20.4
 500 100 10
IB10/B4 Compartment Box Packaging - 1.02X1.02X1.02 (26.0 x 26.0 x 26.0 MM) 10 CELL INSERT BOX IB10/B4 10
1.024
26.0
1.024
26.0
1.024
26.0
5.429
137.9
2.220
56.4
1.276
32.4
 250 50 5
IB05/B4 Sliding Lid Compartment Boxes - 1.02X2.09X.50 (26.0 x 53.0 x 12.8 MM) 5 CELL INSERT BOX IB05/B4 5
1.024
26.0
2.087
53.0
0.504
12.8
5.429
137.9
2.220
56.4
0.756
19.2
 500 100 10
IB05/B5 Plastic Tackle box storage - 1-1/64X2-5/64X35/64 (26.0X53.0X14.0 MM) 5 CELL INSERT BOX IB05/B5 5
1.024
26.0
2.087
53.0
0.551
14.0
5.429
137.9
2.220
56.4
0.803
20.4
 500 100 10
IB05/B6 Insert Boxes with Plastic Dividers - 1.02X2.09X.75 (26.0 x 53.0 x 19.0 MM) 5 CELL INSERT BOX IB05/B6 5
1.024
26.0
2.087
53.0
0.748
19.0
5.429
137.9
2.220
56.4
1.000
25.4
 250 50 5
IB05/B7 Insert Boxes with Plastic Dividers - 1.74X1.46X.32 (44.3 x 37.1 x 8.2 MM) 5 CELL INSERT BOX IB05/B7 5
1.744
44.3
1.461
37.1
0.323
8.2
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB10/C1 Insert Boxes with Moulded Plastic Partitions - 45/64X1-13/64X17/32 (17.8X30.5X13.5 MM) 10 CELL INSERT BOX IB10/C1 10
0.701
17.8
1.201
30.5
0.532
13.5
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
IB05/C1 Carbide Insert Compartment Boxes - 1-13/64X1-13/64X17/32 (30.5X30.5X13.5 MM) 5 CELL INSERT BOX IB05/C1 5
1.201
30.5
1.201
30.5
0.532
13.5
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
IB01/C1 Carbide Insert Compartment Packaging - 3-45/64X2-29/64X17/32 (93.7X62.0X13.5 MM) 1 CELL INSERT BOX IB01/C1 1
3.693
93.8
2.449
62.2
0.532
13.5
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
IB05/C2 Plastic Boxes with Molded Dividers - 45/64X2-29/64X17/32 (17.8X62.2X13.5 MM) 5 CELL INSERT BOX IB05/C2 5
0.701
17.8
2.449
62.2
0.532
13.5
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
IB05/D1 Compartment Box Packaging - 1-13/32X1-13/32X17/32 (35.8X35.8X13.5 MM) 5 CELL INSERT BOX IB05/D1 5
1.409
35.8
1.409
35.8
0.532
13.5
4.508
114.5
2.992
76.0
0.783
19.9
 250 50 5
IB06/D1 Sliding Lid Compartment Boxes - 1.41X1.41X.98 (35.8 x 35.8 x 25.0 MM) 6 CELL INSERT BOX IB06/D1 6
1.409
35.8
1.409
35.8
0.984
25.0
4.508
114.5
2.992
76.0
1.236
31.4
 250 50 5
IB01/D1 Plastic Tackle box storage - 4.32X2.87X.59 (109.8 x 72.8 x 15.0 MM) 1 CELL INSERT BOX IB01/D1 1
4.323
109.8
2.866
72.8
0.591
15.0
4.508
114.5
2.992
76.0
0.843
21.4
 250 50 5
IB05/D2 Insert Boxes with Plastic Dividers - 1.41X1.41X.41 (35.8 x 35.8 x 10.5 MM) 5 CELL INSERT BOX IB05/D2 5
1.409
35.8
1.409
35.8
0.413
10.5
4.508
114.5
2.992
76.0
0.665
16.9
 250 50 5
IB05/D3 Insert Boxes with Plastic Dividers - 1.41X1.41X.98 (35.8 x 35.8 x 25.0 MM) 5 CELL INSERT BOX IB05/D3 5
1.409
35.8
1.409
35.8
0.984
25.0
4.508
114.5
2.992
76.0
1.236
31.4
 250 50 5
IB05/D4 Insert Boxes with Moulded Plastic Partitions - .83X1.56X.59 (21.0 x 39.5 x 15.0 MM) 5 CELL INSERT BOX IB05/D4 5
0.827
21.0
1.555
39.5
0.591
15.0
4.508
114.5
2.992
76.0
0.843
21.4
 250 50 5
Reference # Description Image Cell Count Inside Length
in
mm
 Inside Width
in
mm
 Inside Height
in
mm
 Outside Length
in
mm
 Outside Width
in
mm
 Outside Height
in
mm
 Box/Mini/Micro
QTY		 Buy Online
Legend:
- Add to Cart - Buy now - View Price


message
Warning message embossed on bottom of all items.
Click image to zoom
message
Custom Logos available. Contact us for more information.




Insert Boxes with Plastic Dividers - Information

Insert Boxes with Plastic Dividers are the ideal packaging solution for high quality carbide blade inserts as well as any small delicate set of items that require individual compartmental storage.

Transparent lid offers secure center locking position with quick, simple sliding opening/closing in either direction. Optional custom cut foam inserts are available to provide extra protection for ceramic, diamond and delicate inserts. The Insert Boxes conveniently lock together when stacked and are re-useable.

Insert Boxes with Plastic Dividers are handy packaging options for industries such as fishing, hunting, hobby, craft, hardware, office supplies, medical, dental and many more.

Our Insert Boxes with Plastic Dividers are available in natural or colored Polypropylene (PP) and is 100% recyclable. Custom colors available.

This product can be used to package a wide variety of tooling inserts:
  • Tungsten Carbide Inserts
  • Ceramic Inserts
  • Diamond tools
  • Grooving Inserts
  • HSS Inserts
  • Indexable milling inserts
  • ISO turning inserts
  • Lancing inserts
  • Multi-tooth inserts
  • Parting Inserts
  • Thread milling cutters
  • Thread milling inserts
  • Thread turning inserts


Contact us at 800.649.4980 for pricing, special orders and product information.



RoHS





MOCAP’S QUALITY MANAGEMENT SYSTEM IS NOW CERTIFIED TO ISO 9001:2015 BY ABS QUALITY EVALUATIONS. PLEASE VISIT OUR QUALITY PAGE FOR MORE INFORMATION.
