Foam Insert Boxes

IBF


Carbide Insert Compartment Packaging
Foam Insert Boxes

IBF–Media

Ceramic Inserts Compartment Packaging Foam Miniature Box with Sliding Lid Sliding Lid Compartment Boxes Compartment Box Packaging Carbide Insert Packaging Carbide Insert Compartment Packaging Carbide Insert Compartment Boxes
  • Material: PP (Polypropylene), PVC Foam
  • Foam Protection Ideal for Delicate Ceramic, Diamond, CBN And PCD Inserts
  • Features Individual Compartments
  • Simple Sliding Lid Opens in Either Direction
  • Locks Together When Stacking
  • Suitable for packaging items for vending machine sales
  • Available in a Wide Variety of Sizes, Styles and Cell Counts

Available in the following varieties:

IBM - Insert Boxes (Molded Partitions) Insert Boxes with Plastic Dividers
IBF - Insert Boxes (Foam Partitions) Insert Boxes with Foam Dividers

Size Chart Sliding Lid Compartment Boxes

IBF Size Chart

Table View
List View
Reference # Description Image Cell Count Foam
Cells		 Inside Length
in
mm
 Inside Width
in
mm
 Inside Height
in
mm
 Outside Length
in
mm
 Outside Width
in
mm
 Outside Height
in
mm
 Box/Mini/Micro
QTY		 Buy Online
IB01/M1KF42 Foam Insert Boxes - 5/8X5/8X9/32" (16X16X7MM) 1 FOAM CELL INSERT BOX IB01/M1KF42 1 ✓
0.630
16.0
0.630
16.0
0.276
7.0
2.638
67.0
1.083
27.5
0.622
15.8
 500 100 10
IB01/A1KF29 Insert Boxes with Foam Dividers - 1/2X1/2X5/32" (13X13X4MM) 10 FOAM CELL BOX IB01/A1KF29 10 ✓
0.512
13.0
0.512
13.0
0.157
4.0
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/A1KF27 Insert Boxes with Foam Partitions - 5/8X5/8X5/32" (16X16X4MM) 1 FOAM CELL BOX IB01/A1KF27 1 ✓
0.630
16.0
0.630
16.0
0.157
4.0
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/A1KF30 Carbide Insert Compartment Boxes - 43/64X33/64X5/32" (17X13X4MM) 10 FOAM CELL BOX IB01/A1KF30 10 ✓
0.669
17.0
0.512
13.0
0.157
4.0
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/A1KF32 Carbide Insert Compartment Packaging - 43/64X33/64X5/32" (17X13X4MM) 6 FOAM CELL BOX IB01/A1KF32 6 ✓
0.669
17.0
0.512
13.0
0.157
4.0
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/A1KF31 Carbide Insert Packaging - 1-3/16X19/32X5/32" (30X15X4MM) 5 FOAM CELL BOX IB01/A1KF31 5 ✓
1.181
30.0
0.591
15.0
0.157
4.0
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/A1KF28 Compartment Box Packaging - 3-25/64X1-1/16X5/32" (86X27X4MM) 1 FOAM CELL BOX IB01/A1KF28 1 ✓
3.386
86.0
1.063
27.0
0.157
4.0
3.846
97.7
1.591
40.4
0.488
12.4
 500 100 10
IB01/B1KF33 Sliding Lid Compartment Boxes - 3/4X3/4X13/64" (19X19X5MM) 10 FOAM CELL BOX IB01/B1KF33 10 ✓
0.748
19.0
0.748
19.0
0.197
5.0
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB01/B1KF34 Foam Miniature Box with Sliding Lid - 3/4X3/4X13/64" (19X19X5MM) 5 FOAM CELL BOX IB01/B1KF34 5 ✓
0.748
19.0
0.748
19.0
0.197
5.0
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB01/B1KF35 Foam Insert Boxes - 29/32X3/4X13/64" (23X19X5MM) 10 FOAM CELL BOX IB01/B1KF35 10 ✓
0.906
23.0
0.748
19.0
0.197
5.0
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB01/B1KF36 Insert Boxes with Foam Dividers - 1-3/8X25/64X13/64" (35X10X5MM) 5 FOAM CELL BOX IB01/B1KF36 5 ✓
1.378
35.0
0.394
10.0
0.197
5.0
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB01/B1KF37 Insert Boxes with Foam Partitions - 1-3/8X29/32X13/64" (35X23X5MM) 5 FOAM CELL BOX IB01/B1KF37 5 ✓
1.378
35.0
0.906
23.0
0.197
5.0
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB01/B1KF38 Carbide Insert Compartment Boxes - 1-49/64X25/64X13/64" (45X10X5MM) 10 FOAM CELL BOX IB01/B1KF38 10 ✓
1.772
45.0
0.394
10.0
0.197
5.0
5.429
137.9
2.220
56.4
0.575
14.6
 500 100 10
IB01/C1KF41 Carbide Insert Compartment Packaging - 3/4X3/4X7/16" (19X19X11MM) 5 FOAM CELL BOX IB01/C1KF41 5 ✓
0.748
19.0
0.748
19.0
0.433
11.0
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
IB01/C1KF40 Carbide Insert Packaging - 29/32X25/32X7/16" (23X20X11MM) 2 FOAM CELL BOX IB01/C1KF40 2 ✓
0.906
23.0
0.787
20.0
0.433
11.0
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
IB01/C1KF39 Compartment Box Packaging - 1-1/2X29/32X7/16" (38X23X11MM) 1 FOAM CELL BOX IB01/C1KF39 1 ✓
1.496
38.0
0.906
23.0
0.433
11.0
3.819
97.0
2.598
66.0
0.783
19.9
 500 100 10
Reference # Description Image Cell Count Foam
Cells		 Inside Length
in
mm
 Inside Width
in
mm
 Inside Height
in
mm
 Outside Length
in
mm
 Outside Width
in
mm
 Outside Height
in
mm
 Box/Mini/Micro
QTY		 Buy Online
Legend:
- Add to Cart - Buy now - View Price


message
Warning message embossed on bottom of all items.
Click image to zoom
message
Custom Logos available. Contact us for more information.




Foam Insert Boxes - Information

Foam Insert Boxes are the ideal packaging solution for high quality carbide blade inserts as well as any small delicate set of items that require individual compartmental storage.

Transparent lid offers secure center locking position with quick, simple sliding opening/closing in either direction. The die-cut foam provides extra protection for ceramic, diamond and delicate inserts. The Insert Boxes conveniently lock together when stacked and are re-useable.

Foam Insert Boxes are handy packaging options for industries such as fishing, hunting, hobby, craft, hardware, office supplies, medical, dental and many more.

Our Foam Insert Boxes are available in natural or colored Polypropylene (PP) and is 100% recyclable. Custom colors available.

This product can be used to package a wide variety of tooling inserts:
  • Tungsten Carbide Inserts
  • Ceramic Inserts
  • Diamond tools
  • Grooving Inserts
  • HSS Inserts
  • Indexable milling inserts
  • ISO turning inserts
  • Lancing inserts
  • Multi-tooth inserts
  • Parting Inserts
  • Thread milling cutters
  • Thread milling inserts
  • Thread turning inserts


Contact us at 800.649.4980 for pricing, special orders and product information.
